Real HD Industrial 4-Port Full Gigabit DIN-Rail PoE Switch with UL Power
Industrial Gigabit PoE+ switch with four powered ports, dual Gigabit uplinks, DIN-rail mounting, 60W PoE budget, and included UL power supply.
In stock
Questions about compatibility, PoE power, or choosing the right port count? [Ask a CCTV Specialist]
Installer or Dealer? Request Trade Pricing.
Ships from Bensenville, IL
Fast Order Processing
1-Year Warranty
30-Day Return Window
This industrial Gigabit PoE+ switch is designed for surveillance and network installations that need reliable PoE connectivity in equipment cabinets, control panels, and other DIN-rail environments. Four Gigabit PoE ports power and connect compatible cameras and network devices, while two dedicated Gigabit uplinks connect to an NVR, router, or upstream network.
The DIN-rail design, IP40 metal housing, and wide operating temperature range make the switch suitable for demanding commercial and industrial installations. An included UL power supply provides the required power source for the switch.
Plug-and-play unmanaged operation requires no switch-level configuration, making it practical for installers who need a compact industrial PoE solution without adding network management complexity.
Key Benefits
- Industrial DIN-Rail Installation – Mounts inside compatible control cabinets and equipment enclosures for organized network installations.
- Four Gigabit PoE Connections – Powers and connects up to four compatible PoE cameras or other supported network devices.
- Dedicated Gigabit Uplinks – Connects to compatible NVRs, routers, or upstream switches without using the four powered device ports.
- Built for Demanding Locations – IP40 metal construction and wide-temperature operation support commercial and industrial environments.
Recommended Applications
- Industrial Surveillance Systems
- Warehouse Camera Networks
- Factory Security Installations
- Equipment and Control Cabinets
- Commercial DIN-Rail Networks
- Remote IP Camera Installations
| Network Interface | |
|---|---|
| PoE Ports | 4 × Gigabit Ethernet PoE ports |
| Uplink Ports | 2 × Gigabit Ethernet uplink ports |
| PoE | |
|---|---|
| PoE Standards | IEEE 802.3af, IEEE 802.3at |
| Maximum Power per Port | Up to 30 W |
| Total PoE Power Budget | 60 W |
| Installation & Environmental | |
|---|---|
| Mounting | DIN rail |
| Enclosure | IP40-rated metal enclosure |
| Operating Temperature | -40°C to 75°C |
| General | |
|---|---|
| Product Type | Industrial Gigabit PoE+ Switch |
| Management Type | Unmanaged |
| Power Supply | Industrial UL power supply included |
Find answers to common questions about compatibility, PoE power, supported equipment, product selection, and use with security camera and surveillance systems.
What is this industrial PoE switch used for?
It is designed to provide Gigabit network connectivity and PoE power for up to four compatible devices in DIN-rail surveillance, control cabinet, and commercial network installations.
How many PoE cameras can the switch connect?
The switch provides four Gigabit PoE ports and can connect up to four compatible PoE cameras or other powered devices. Their combined power requirement must remain within the 60W total PoE budget.
What are the two Gigabit uplink ports used for?
The two dedicated Gigabit uplink ports can connect the switch to a compatible NVR, router, or upstream network switch without using any of the four PoE device ports.
Can this switch be installed on a DIN rail?
Yes. The switch is designed for standard DIN-rail mounting in compatible equipment cabinets and control enclosures.
What operating temperature range does the switch support?
The listed operating temperature range is -40°C to 75°C. Installation should still follow the documented environmental and electrical requirements for the intended location.
